F-500 EA Diamond Doser Fixed Fire Protection Pump

F-500 EA®
Diamond Doser®
Fire Suppression System

Proportion F-500 EA®
Concentrate for Deployment

The Diamond Doser® is a water-driven volumetric proportioner designed to seamlessly and precisely inject F-500 EA® concentrate into your water stream for immediate deployment. Trusted by firefighters and industry leaders worldwide, it delivers exceptional performance in high-hazard firefighting and fire protection—consistently exceeding industry standards.

F-500 EA®

Concentrate

Request Quote

Diamond Doser®

Mobile Unit

Request Quote

Diamond Doser®

Fixed Unit

Request Quote

Specification

MODEL #	MINIMUM FLOW	MAXIMUM FLOW	INLET/OUTLET
DD-00180	50 LPM (13 GPM)	180 LPM (48 GPM)	DN 40 (NPS 1-1/2)
DD-00450	85 LPM (22 GPM)	450 LPM (119 GPM)	DN 50 (NPS 2)
DD-00800	150 LPM (40 GPM)	800 LPM (211 GPM)	DN 65 (NPS 2-1/2)
DD-01200	180 LPM (48 GPM)	1,200 LPM (317 GPM)	DN 80 (NPS 3)
DD-01800	200 LPM (53 GPM)	1,800 LPM (476 GPM)	DN 100 (NPS 4)
DD-02400	260 LPM (69 GPM)	2,400 LPM (634 GPM)	DN 100 (NPS 4)
DD-03200	300 LPM (79 GPM)	3,200 LPM (846 GPM)	DN 150 (NPS 6)
DD-04000	400 LPM (106 GPM)	4,000 LPM (1,058 GPM)	DN 150 (NPS 6)
DD-04500	400 LPM (106 GPM)	4,500 LPM (1,190 GPM)	DN 150 (NPS 6)
DD-06000	500 LPM (132 GPM)	6,000 LPM (1,587 GPM)	DN 150 (NPS 6)
DD-08000	800 LPM (212 GPM)	8,000 LPM (2,116 GPM)	DN 200 (NPS 8)
DD-10000	1,000 LPM (264 GPM)	10,000 LPM (2,645 GPM)	DN 250 (NPS 10)

F-500 EA®

NFPA 18A-Compliant
Encapsulator Technology

F-500 EA® is an advanced Encapsulator Agent used for fire suppression, vapor mitigation, spill control, and contamination response. Manufactured in the USA at our Georgia headquarters since 1997, this proven technology is now trusted worldwide by firefighters and industry leaders to address Class A, Class B, Class C, Class D, and lithium-ion battery hazards.

Request Quote

What is F-500 EA®?

F-500 EA® is an Encapsulator Agent recognized in NFPA 18A, Standard on Water Additives for Fire Control and Vapor Mitigation. This is the first standard outlining the criteria an agent must meet to be classified as an Encapsulator Agent. The Spherical Micelle Stability Test protocol in Section 7.7 evaluates a concentrate’s ability to form stable spherical micelles which are capable of encapsulating hydrocarbon based fuels, rendering them nonflammable.

Foams work on a mechanical level, relying on a bubble blanket to separate the fuel from the oxygen. Unlike foams, Encapsulator Agents like F-500 EA® work on a molecular level, relying on spherical micelles to encapsulate fuel. These spherical micelles work on all four legs of the fire tetrahedron simultaneously to deliver three unique features: encapsulation, rapid heat reduction, and free radical interruption.

Why should we buy fluorine-free F-500 EA® over fluorine-free foam?

Technology is advancing faster than the codes and standards issued by leading regulatory agencies, leaving firefighters and industry leaders unprepared for the complex challenges of modern fires. In response, many organizations have begun switching to fluorine-free foams in search of a “safer” solution. However, these foams often fall short when faced with high-hazard scenarios.

While fluorine-free foams can be effective in certain situations, NFPA 11 clearly states that foam is not suitable for combating three-dimensional or flowing fuel fires. To provide comprehensive protection across multi-class hazards—including three-dimensional and flowing fuel fires—an alternative solution is required. That solution is fluorine-free F-500 EA®.

F-500 EA® goes beyond traditional fire suppression. In addition to extinguishing modern fires effectively, it actively reduces the concentration of flammable, explosive, and toxic vapors present during an emergency—protecting firefighters, personnel, and civilians in ways that neither foam nor water alone can achieve.

Is F-500 EA® recognized by leading life safety institutions?

Yes!

UL NFPA 18
Tests a wetting agent’s ability to mitigate Class A and Class B fire hazards as well as flammable spill control.

NFPA 18A Section 7.7
Tests an Encapsulator Agent’s ability to render hydrocarbon based fuels nonflammable.

NFPA 18A Annex 4.3
Recognizes third-party scientific testing of Encapsulator Agents on lithium-ion battery fire hazards.

NEN NTA 8133
Tests a fire extinguisher’s ability to extinguish lithium-ion battery fires up to 600 Wh.

FAA AC 150/5210-6E Circular
Includes Encapsulator Agents in an advisory circular on aircraft fire extinguishing agents for airports.

What types of fires can F-500 EA® extinguish?

F-500 EA® can efficiently extinguish blazes containing mixed materials.

Class A
Wildland Fires, Wood, Paper, Cloth, Rubber, Plastic, Coal, Etc.

Class B (2D)
Gasoline, Diesel Fuel, Oil, E10, E85, Ethanol, Methanol, Jet Fuel, Etc.

Class B (3D)
Transformers, Oil Rigs, Aircraft Turbines, Distillation Columns, Etc.

Class C (Energized Environments)
Solar Panel Installations, Charging Stations, Substations, Etc.

Class D
Magnesium, Titanium, Aluminum, Zirconium, Lithium, Etc.

Lithium-ion Batteries
Battery Energy Storage Systems, EVs, E-bikes, Phones, Laptops, Etc.

Diamond Doser®

Mobile Firefighting for
Hydrants and Fire Trucks

The Diamond Doser® mobile unit is a convenient proportioner for fire departments seeking greater flexibility and coverage on the fireground. It excels in firefighting operations on airport tarmacs, offshore vessels, wildlands, and more, providing firefighters with continuous access to a consistent flow of F-500 EA® solution in all directions.

Request Quote

What is the Diamond Doser® mobile unit?

The Diamond Doser® is a one of a kind proportioning pump engineered to work hand-in-hand with NFPA 18A-compliant Encapsulator Agents. It’s driven by water flow alone, consistently proportioning F-500 EA® concentrate into your water stream to mitigate Class A, Class B, Class C, Class D, and lithium-ion battery fire hazards.

Why should we buy the Diamond Doser® over an electric proportioner?

With the Diamond Doser®, fire departments can easily set up a system that adapts to a wide range of firefighting scenarios. Multiple nozzles can be used simultaneously, even when positioned at varying lengths and heights. The Diamond Doser® also enables the rapid opening and closing of nozzles—ideal for pulsing techniques—while ensuring immediate and accurate proportioning of F-500 EA® concentrate at all times.

How do we use the Diamond Doser® mobile unit?

Diamond Doser® mobile units come fully equipped with a suction tube that can be inserted directly into an F-500 EA® concentrate pail, drum, or tote. Each unit features an automatic air relief valve for faster priming, along with a bottom bracket and carrying handle—or an optional cage frame—for easy transport. For larger models, we add wheels to ensure effortless mobility.

Do you sell firefighting hoses?

No, we do not sell firefighting hoses.

Diamond Doser®

Fixed Fire Protection for
Deluge and Sprinkler Systems

The Diamond Doser® fixed unit is a gamechanging proportioner for industry leaders looking to limit damage, loss, and downtime. It consistently proportions F-500 EA® concentrate into any new or existing deluge or sprinkler system for all-encompassing fire protection that prioritizes the health and safety of building occupants as well as structural integrity.

Request Quote

What is the Diamond Doser® fixed unit?

Why should we buy the Diamond Doser® over a bladder tank?

The Diamond Doser® offers several benefits that a bladder tank cannot.

Superior Protection
Make F-500 EA® your fire suppression agent of choice for multi-class and three-dimensional protection against high hazards like lithium-ion batteries. The Diamond Doser® automatically adjusts dosing as more heads open.

Eco-friendly Operation
F-500 EA® is a fluorine-free, biodegradable, and noncorrosive agent that delivers effective fire suppression while reducing your environmental impact and costly disposal fees—combining performance with sustainability.

Low Maintenance
No manual calibration or lubrication is required. Simply crank the shaft of your Diamond Doser® every two months with a ratchet wrench. Safely refill your atmospheric tank with F-500 EA® concentrate as needed for a continuous flow.

Economical Testing
Enjoy annual savings on NFPA-mandated testing that doesn’t generate F-500 EA® solution while simplifying the testing process with an accessible atmospheric tank when you add a Dosing Return Valve (DRV) to your Diamond Doser®.

Is the Diamond Doser® recognized by leading life safety institutions?

Yes!

Applus+
The Diamond Doser® is internationally approved by Applus+ and certified under ETI 23/32306438. Applus+, a global leader in Testing, Inspection, and Certification (TIC), operates in over 95 locations worldwide. Their fire test results are widely recognized, including by UL Solutions in numerous countries.

DEKRA
Following Applus+’s international approval, DEKRA has recommended F-500 EA® for use in fire suppression systems designed to protect against lithium-ion battery hazards. DEKRA is a global leader in vehicle Testing, Inspection, and Certification (TIC), operating from 480 branches across Germany and conducting inspections at over 38,500 locations.

Fire Insurers Laboratories of Korea (FILK)
F-500 EA® is now FILK-certified after successfully extinguishing a Hyundai Kona Electric—with a 64 kWh battery—in just 8 minutes and 30 seconds during an Electric Vehicle Fire Suppression Test at FILK’s KOLAS-accredited laboratory. FILK is a leading fire safety testing institution, recognized by the American National Standards Institute (ANSI).

Do you install deluge and sprinkler systems?

We do not install deluge or sprinkler systems. However, our in-house engineering team collaborates closely with project designers and contractors to develop and implement comprehensive fire protection solutions using the Diamond Doser® and F-500 EA®.
