F-500 EA®
Fire Suppression Systems
F-500 EA® Micelle Mist
Micelle Mist is redefining water mist with F-500 EA®, the proven solution for lithium-ion battery fires. Offered in low-pressure and high-pressure continuous-flow or stand-alone configurations, F-500 EA® Micelle Mist mitigates hazards that water mist alone cannot address effectively in BESS, Parking Garages, EV Charging Stations, Data Centers, and Ro-Ro Ships.
F-500 EA® Diamond Doser®
The Diamond Doser®, powered by Firemiks®, is a water-driven volumetric proportioner designed to seamlessly inject F-500 EA® concentrate into your water stream for immediate deployment. Trusted by firefighters and industry leaders worldwide, it delivers exceptional performance in high-hazard firefighting and fire protection—consistently exceeding industry standards.
Firemiks®
Firemiks® volumetric foam proportioner systems provide efficient, environmentally responsible fluorine-free fire suppression ideal for both Class A and Class B firefighting and fire protection. Transitioning to fluorine-free foam often requires a redesigned setup and a larger concentrate tank—making it the perfect time to upgrade to a cost-effective, state-of-the-art Firemiks® system.
F-500 EA® Bladder Tank
The F-500 EA® Bladder Tank System is engineered for high-hazard areas in defined spaces. Available in sizes from 136 L (36 G) to 45,425 L (12,000 G), each pressure-rated vessel features an internal bladder storing F-500 EA® concentrate. On activation, water pressure compresses the bladder to deliver a 1%–3% F-500 EA® solution to deluge or sprinkler heads.
F-500 EA® EV FirePro
F-500 EA® EV FirePro is a revolutionary fire suppression system engineered to combat electric vehicle fires at their source, preventing spread in parking facilities. Available in three tailored configurations—Domestic, Plus, and Signature—it provides scalable EV fire protection for everything from residential townhouses to multi-level commercial complexes with over 20 specialized under-vehicle nozzles per unit.
Frequently Asked Questions
What is an Encapsulator Agent?
Foams work on a mechanical level, relying on a bubble blanket to separate the fuel from the oxygen. Unlike foams, Encapsulator Agents work on a molecular level, relying on spherical micelles to encapsulate fuel. These spherical micelles work on all four legs of the fire tetrahedron simultaneously to deliver three unique features: encapsulation, rapid heat reduction, and free radical interruption.
Encapsulator Agents are recognized in NFPA 18A, Standard on Water Additives for Fire Control and Vapor Mitigation. This is the first standard outlining the criteria an agent must meet to be classified as an Encapsulator Agent. The Spherical Micelle Stability Test protocol in Section 7.7 evaluates a concentrate’s ability to form stable spherical micelles which are capable of encapsulating hydrocarbon and polar based fuels, thereby rendering them nonflammable.
Why should we buy F-500 EA® over Fluorine Free Foam?
Technology is outpacing the codes and standards put out by leading regulatory agencies. This has left markets and first responders unprepared for many of the challenges and hazards associated with today’s industrial fires. Many organizations are switching to Fluorine Free Foam (FFF) for “safe” protection, but these foams aren’t capable of mitigating the high hazards they’re faced with.
Although traditional compressed air foam systems can be useful under specific circumstances, NFPA 11 states that foam is an inappropriate choice for fighting three-dimensional and flowing fuel fire hazards. For all-encompassing fire protection covering multi-class, three-dimensional, and flowing fuel hazards, an alternative is needed. That’s where fluorine free Encapsulator Technology comes into play.
What types of fires can F-500 EA® extinguish?
F-500 EA® can effectively extinguish blazes containing mixed materials.
Class A
Wildland Fires, Wood, Paper, Cloth, Rubber, Plastic, Coal, Etc.
Class B (2D)
Gasoline, Diesel Fuel, Oil, E10, E85, Ethanol, Methanol, Jet Fuel, Etc.
Class B (3D)
Transformers, Oil Rigs, Aircraft Turbines, Distillation Columns, Etc.
Energized Environments
Solar Panel Installations, Charging Stations, Substations, Etc.
Class D
Magnesium, Titanium, Aluminum, Zirconium, Lithium, Etc.
Lithium-ion Batteries
Battery Energy Storage Systems, EVs, E-bikes, Phones, Laptops, Etc.
Is F-500 EA® recognized by leading life safety institutions?
Yes!
UL NFPA 18
Tests a wetting agent’s ability to mitigate Class A and Class B fire hazards as well as flammable spill control.
NFPA 18A Section 7.7
Tests an Encapsulator Agent’s ability to render hydrocarbon and polar based fuels nonflammable and nonignitable.
NFPA 18A Annex 4.3
Recognizes third-party scientific testing of Encapsulator Agents on lithium-ion battery fire hazards.
NEN NTA 8133
Tests a fire extinguisher’s ability to extinguish lithium-ion battery fires under 600 Wh.
FAA AC 150/5210-6E Circular
Includes Encapsulator Agents in an advisory circular on aircraft fire extinguishing agents for airports.
What percentage of F-500 EA® do we need in our solution?
Please consult all appropriate F-500 EA® SOGs for more information.
Class A
0.5%-1% F-500 EA®
Class B (2D)*
3% F-500 EA®
Class B (3D)
3% F-500 EA®
Energized Environments
3% F-500 EA®
Class D
3% F-500 EA®
Lithium-ion Batteries
3% F-500 EA®
*Although F-500 EA® can quickly extinguish a Class B fire, this is not to be confused with fuel spill neutralization. To encapsulate an entire hydrocarbon fuel spill, you will need to know how much fuel has been spilled. For fuel neutralization, the ratio is 1 part F-500 EA®, 8 parts fuel, and 40 parts water. For example, a typical 8-gallon fuel spill would require one gallon of F-500 EA® and 40 gallons of water to render the spill nonflammable and nonignitable. It can then be left to evaporate, depending on local regulations.
Is F-500 EA® environmentally friendly?
Yes! F-500 EA® is fluorine free, biodegradable, and noncorrosive.
Nontoxic & Non-Skin Sensitizing
F-500 EA® was found to be non-sensitizing when tested in accordance with OECD-406.
Non-hazardous
F-500 EA® does not contain any ingredients reportable under the Superfund Amendments, Re-authorization Act (SARA) Title III, Section 313, or Comprehensive Environmental Response Compensation Liability Act (CERCLA). It can be discarded as a non-hazardous waste under RCRA CFR261.
Biodegradable
Testing shows that F-500 EA® is fully biodegradable. As with any substance, care should be taken to prevent uncontrolled discharge from entering ground water, surface water, or storm drains. With advance notice, F-500 EA® can be treated by local biological wastewater treatment plants. The lower the Biochemical Oxygen Demand (BOD) and Chemical Oxygen Demand (COD), the lower the demand for oxygen and the better for the aquatic ecosystem. When compared to several AR-AFFF products, F-500 EA®’s BOD is 87% less and its COD is 80% less.
EPA NCP Product Schedule Listed
F-500 EA® is listed on the National Contingency Plan Product Schedule of the U.S. Environmental Protection Agency (EPA) as a surface washing agent.
What is the shelf life of F-500 EA®?
The shelf life of an unopened container of F-500 EA® concentrate is at least 15 years. Testing is ongoing.
Is F-500 EA® approved by the Insurance Services Office (ISO)?
Yes! F-500 EA® is recognized by the Insurance Services Office (ISO) as a foam equivalent and therefore qualifies for point credit recognition.
Where can I buy F-500 EA®?
F-500 EA® is available across the globe! Please contact us directly to receive a quote on domestic and international sales. If we have a distributor in your region, we’ll connect you with them, giving you the opportunity to purchase F-500 EA® locally.
How long have you been selling F-500 EA®?
We’ve been selling F-500 EA® since 1997. Over the years, it has gained worldwide recognition as an innovative agent for firefighters and industry leaders looking to transition to a sustainable future.
Where can I get a Safety Data Sheet (SDS) for F-500 EA®?
Please contact us directly to receive a Safety Data Sheet (SDS) for F-500 EA®.
